Class C motorhome chassis guide
The Ford E-350 supports many compact Class C and B+ motorhomes. Once the coach body, tanks, storage, and equipment are added, ride and handling can change considerably. Start with the problem you want to fix, then confirm the chassis year and rear-wheel configuration before ordering.
Start with the symptom
One component cannot correct every ride and handling complaint. Use this chart to identify the best place to start.
| What you feel | Start with | What it addresses |
|---|---|---|
| Repeated bounce or porpoising | Shocks | Controls suspension movement after dips, bridge joints, and uneven pavement. |
| Excessive lean in turns or driveways | Anti-sway bars | Reduces side-to-side body roll without carrying the coach's weight. |
| Constant steering corrections | Alignment and steering stabilizer | Helps the steering return toward center and improves control in crosswinds. |
| The coach shifts sideways over bumps | Rear trac bar | Limits lateral movement between the rear axle and chassis. |
| Rear sag or frequent bottoming | Weight check and spring support | Restores support when the chassis is within its ratings but needs help carrying its normal load. |
| Uneven tire wear or pulling | Inspection and loaded alignment | Finds tire, steering, suspension, or alignment problems before parts are added. |
Shock choices
Both are established RV shock brands. The better choice depends on how you want the coach to feel and which application is cataloged for your chassis year.
KONI FSD shocks are a strong choice when you want to reduce harshness over expansion joints and broken pavement without giving up control during slower body movement. They are often the best fit for owners who want a more settled ride without a consistently firm feel.
Bilstein B6 shocks are a good fit for drivers who prefer a direct, controlled feel from a monotube shock. Comfort and Heavy Duty listings are not interchangeable across every year, so confirm the exact front and rear application before ordering.
Use the same shock model on the left and right side of each axle. Mixing front and rear models can be appropriate only when both applications are listed for the coach and the combination solves a specific ride problem. Do not mix parts to compensate for worn springs, excess load, or a steering problem.
Build the right system
If shocks are only part of the problem, these components target the movement that shocks do not control.
Reduce body roll in corners, driveways, crosswinds, and passing-truck turbulence.
Learn about anti-sway barsAdd centering force to the steering and help reduce the corrections needed to hold a straight path.
Shop Safe-T-PlusControl side-to-side movement between the rear axle and frame, often described as tail wag.
Learn about rear trac barsAdd support for a coach that sits low or bottoms out while operating within its weight ratings.
Learn about helper springsAlign the motorhome at its normal travel weight, with tire pressures set from actual axle loads.
Find an installerLearn how shocks, sway bars, steering parts, springs, and load distribution work together.
Read the complete suspension guideA Quigley conversion changes the front suspension and shock fitment. Do not order standard E-350 front shocks for a converted van without checking the conversion details.
View the Ford E-350 Quigley guideFitment details
The motorhome model year and the Ford chassis year may be different. That is one of the most common sources of incorrect RV suspension orders.
Select the Ford chassis year, E-350 model, and product position at the top of this page. If the coach year does not match the chassis label or you have added suspension equipment, contact us before ordering.
Common questions
Send us the chassis year, VIN details, coach make and model, and a short description of the problem. We will help narrow down the right parts.
